Besen SQ20-22KW-APP Wall-Mounted Charger for Electric Cars
In stock
Besen SQ20-22KW-APP Wall-Mounted Electric Car Charger
The SQ20-APP is designed for wall mounting and is ideal for both residential and professional use. By connecting to the app via Bluetooth, you can remotely set the charging time and current, start and stop charging, and view your charging history at any time.
Advanced technology and easy operation
The charger is equipped with a 3.5-inch color LCD display that shows real-time charging parameters—time, voltage, current, temperature, and energy consumption. A built-in smart chip automatically diagnoses and corrects errors not caused by hardware malfunctions, which enhances charging safety and reliability. You can also update the software via the app, allowing for easy implementation of new features.
Safety and Compatibility
The Wallbox SQ20-APP features a comprehensive set of safety protections: against overvoltage, overheating, overload, short circuits, ground faults, and lightning strikes. It supports SAE J1772, IEC 62196-2, and GB/T interfaces, making it compatible with most electric vehicles available on the market. The maximum charging current is 32 A, and the IP66-rated housing ensures resistance to dust and water.
Included in the set:
- Charger
- User manual
- Foldable card with quick start guide
- Positioning paper
- Mounting screws
- Metal hanger
| Manufacturer | Besen |
|---|---|
| Model | SQ20-22KW-APP |
| Output power | 22 kW |
| Input/output voltage | AC 400V (3-phase) |
| Maximum current | 32 A |
| Frequency | 47–63 Hz |
| Charging interface | SAE J1772, IEC 62196-2, GB/T |
| Display | 3.5” color LCD |
| Water resistance | IP66 |
| Weight | 8 kg |
| Dimensions | 295 × 195 × 65 mm |
| Ambient temperature | -25°C ~ +55°C |
| Humidity | 0–95% non-condensing |
| Max. altitude | <2000 m |
| Standby power consumption | <8 W |
| App | EVSEMaster |
Product description
Besen SQ20-22KW-APP Wall-Mounted Electric Car Charger
The SQ20-APP is designed for wall mounting and is ideal for both residential and professional use. By connecting to the app via Bluetooth, you can remotely set the charging time and current, start and stop charging, and view your charging history at any time.
Advanced technology and easy operation
The charger is equipped with a 3.5-inch color LCD display that shows real-time charging parameters—time, voltage, current, temperature, and energy consumption. A built-in smart chip automatically diagnoses and corrects errors not caused by hardware malfunctions, which enhances charging safety and reliability. You can also update the software via the app, allowing for easy implementation of new features.
Safety and Compatibility
The Wallbox SQ20-APP features a comprehensive set of safety protections: against overvoltage, overheating, overload, short circuits, ground faults, and lightning strikes. It supports SAE J1772, IEC 62196-2, and GB/T interfaces, making it compatible with most electric vehicles available on the market. The maximum charging current is 32 A, and the IP66-rated housing ensures resistance to dust and water.
Included in the set:
- Charger
- User manual
- Foldable card with quick start guide
- Positioning paper
- Mounting screws
- Metal hanger
| Manufacturer | Besen |
|---|---|
| Model | SQ20-22KW-APP |
| Output power | 22 kW |
| Input/output voltage | AC 400V (3-phase) |
| Maximum current | 32 A |
| Frequency | 47–63 Hz |
| Charging interface | SAE J1772, IEC 62196-2, GB/T |
| Display | 3.5” color LCD |
| Water resistance | IP66 |
| Weight | 8 kg |
| Dimensions | 295 × 195 × 65 mm |
| Ambient temperature | -25°C ~ +55°C |
| Humidity | 0–95% non-condensing |
| Max. altitude | <2000 m |
| Standby power consumption | <8 W |
| App | EVSEMaster |
